Automatic Frame Glue Dispensing Machine

Automatic Glue Dispensing System for Frame Assembly:
Our advanced Automatic Glue Dispensing System automatically applies glue evenly to frames, ensuring consistent bonding and improved production efficiency. Acting as a high-performance Glue Frame Integrated Machine, it minimizes labor costs and material waste in the manufacturing of solar modules, windows, and door frames. Additionally, its robust design makes it an ideal Framing Machine for integration into a Solar Panel Production Line.

CNC-Controlled Automatic Glue Application for Precision Frame Production:
Utilizing a CNC-controlled process, this system precisely manages glue application with adjustable speed settings. Whether deployed as an Automatic Glue Dispensing System or used as a Glue Frame Integrated Machine in high-precision frame assembly, it delivers uniform glue application across various frame sizes. This efficiency enhances the capabilities of any Framing Machine on a Solar Panel Production Line, speeding up production and reducing waste.

Features

• CNC System Control: The machine integrates CNC system automatic control with manual feeding, automatic cutting, clamping, and gluing—offering a complete solution as an Automatic Glue Dispensing System and Glue Frame Integrated Machine without the need for an artificial support frame.

• Even and Stable Glue Application: Ensures that glue is distributed evenly and stably, eliminating the need for reapplication. This capability saves labor, time, and material, making it a superior Framing Machine option for a Solar Panel Production Line.

• Stepless Speed Regulation: Both glue dispensing and transmission speeds are computer-controlled with stepless adjustments. This feature simplifies operation and enhances the overall performance of the Automatic Glue Dispensing System.

Specifications

• Working Speed: 6–26 M/S; ≤32 seconds per full set frame.

• Max. Length: 2200 mm.

• Min. Length: 270 mm (ultra-short customized).

• Max. Width: 55 mm.

• Min. Width: 17 mm.

• Glass Groove Depth: 8–15 mm.

• Power Supply: 220V 50 Hz.

• Equipment Power: X-axis 200W, Total 2200W.

• Air Source: Pressure 0.5–0.6 MPa.

• Glue Barrel Inner Diameter: Approximately 565–571 mm.

• Environmental Temperature: 0℃–40℃.

• Environmental Humidity: Less than 95%.
